1920x1080 Resolution Interactive Video Wall For Security Monitoring Center

1920x1080 Resolution Interactive Video Wall For Security Monitoring Center

  • 1920x1080 Resolution Interactive Video Wall For Security Monitoring Center
1920x1080 Resolution Interactive Video Wall For Security Monitoring Center
Product Details:
Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: DDW-LW460HN09
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: L/C , L/C , T/T
Supply Ability: 3 , 000pcs per month
Contact Now
Detailed Product Description
Product Name: Interactive Video Wall Application: Security Monitoring Center
Total Physical Bezel: 5.3mm Color: 8Bit,16.7M
Daisy Chain: RJ45 Loop Input Voltage: 230W
Surface: Anti-glare Working Humidity: 0.85
Highlight:

interactive video display

,

interactive touch screen video wall

1920x1080 Resolution Interactive Video Wall For Security Monitoring Center


Interactive Video Wall Specifications

1. - LED backlight 500nits brightnes
2. - 100% New Samsung screen
3. Origianl Samsung DID panel
4. 5.3mm ultra narrow bezel lcd video wall screen
5. The world first &Best seller lcd video wall screen!!
6. Most cost-effective lcd video wall solution screen in the world
7. Model No.: DDW-LW460HN09

Interactive Video Wall features:

1, Original DDW Industrial grade Samsung lcd video wall solution screen,16:9 LG a-Si TFT-LCD
2, 500nits brightness,4000:1 contrast,HD lcd video wall unit--- High brightness,high contrast,High gamut .
3, HD physical resolution 1920x1080
4, Only 5.3mm ultra narrow bezel.high quality ,Practical ,good vision effect.
5, Interface --- 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output
6, Flexible structure design ---easy installation ,extensible,arbitrary combination
7, Stable performance,suitable working for a long time

46" lcd video wall is one of DDW most popular video wall panels which has 5.3mm ultra narrow bezel,FHD1920x1080 resolution,and 500nits brightness,it's one of first Samsung general videowall panels in the world.

DDW lcd video wall can be used in below fields: Conference and meeting rooms, office building, lobbies, security monitoring center, surveillance and retail center, restaurant and hotel, retail shopping mall advertising and information displays, public installations, exhibition and show center, live show,rental and advertising center,museums,church,transportation and mass info display systems.

Interactive Video Wall Panel Specifications


Active Screen Diagonal46" 16:9
Bezel WidthTotal: 5.3 mm
Aspect Ratio16:9
Physical Resolution1920x1080
Backight SystemLED
Luminance(nits)500cd/sqm
ContrastMEGA DCR
Viewing AngleH 178°|V 178°
Panel Dimension(WxHxD)1023.98×578.57x79.5mm
White Point10,000 K
Display Colors8Bit,16.7M
Refresh Rate60Hz
Response Time<=6ms
Life(hrs)>60,000(hrs)
MTBF> 100,000 h
SurfaceAnti-glare
Standby Power Consumption<3W
Maximum Power Consumptionlower than 250W
Power SupplyAC100~240V 50/60 HZ
CoolingLow noise fans
Heat Dissipation819 BTU/h (max)
Working Time Capacity7x24x365hours
Application AreaIndoor/Semi Outdoor
Working Temperature0°C~50°C
Working Humidity0.85
Storage Temperature-20-60°C | -4-140°F
Storage Humidity85% non-condensing


Interactive Video Wall Board Specifications


SupportPCColor24bit
Signal Line synchronization range30-80KHZ
Field synchronization range50-75HZ

DVI

HDMI

DP

Color24bit
Line synchronization range30-80KHZ
Field synchronization range50-75HZ
InterfaceInputVGA x 115pin D-Sub
DVI x 1DVI-I
DP x 1Display Port
HDMI x 2HDMI-19 pin
OutputPANELLVDS 36Pin/2.0
DP outDP loop out
PowerInput powerDC24V/12V/5V
Drive panel5V/12V
Power modeNormal working mode, power saving mode
OtherOSDChinese, English and other languages (other languages can be added as required)
