Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall

Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall

    • Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall
    • Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall
    • Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall
  • Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW550HN16

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Interactive Video Wall Backlight: LED
    Resolution: 1920*1080 Input Voltage: AC 220v-250v
    Total Physical Bezel: 1.7mm Refresh Rate: 60Hz
    Panel Size: 55'' Panel Height: 682.34 Mm
    High Light:

    interactive video display

    ,

    interactive touch screen video wall

    LW550HN16 55 Inch Interactive Video Wall Seamless Refresh Rate 60Hz





    Narrow Bezel:

    •  55 inch LCD video wall narrow bezel available: 1.7 mm, 1.8 mm, 3.5 mm;
    •  Interactive Video Wall show commercial advertisement, food picture, video play, product picture;

    View Angle

    •  178 degree wide viewing angle, the full range of display;
    •  Different modules optional: such as heating module, built in camera, air conditioner etc;

    HD Panel Display

    •  HD video wall unit: high brightness, contrast and gamut.
    •  Resolution: 1920×1080, 3840×2160; Color: 16.7M; Brightness: 500cd/m2;

    Functions:

    •  Supporting 225 units (15×15) multi-matrix;
    •  Single screen display. Each unit can display the picture independently;
    •  Image overlay. Superimposed on screen another picture;
    •  Easy to choose full screen or multi-screen display by control video wall controller.

     Panel dimension and interfaces:

    •  Dimension: 1211.54 x 682.34 mm;
    •  Interface --- 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output

    Total bezel width

    •  Bezel size: 1.7 mm;
    •  The front shell adapting black matt anti magnetic unique and exquisite strong in anti interface;

    Connection topology and applications:

    •  Supports multiple signal input: BNC, YPbPr, VGA, HDMI, DVI and RS232;
    •  Applications: Financial center, real estate center, security room, cinema, theater, etc;

    Specifications:

    Model No: DDW-LW550HN16
    LCD Technology LG IPS LCD
    Active Screen Diagonal 55"
    Total Bezel Width 1.7 mm
    Aspect Ratio 16:9
    Physical Resolution 1920x1080
    Backight System LED
    Luminance(nits) 500 cd/sqm
    Contrast MEGA DCR
    Viewing Angle H 178°|V 178°
    Panel Dimension(WxHxD) 1211.54×682.34x68.1mm
    White Point 10,000 K
    Display Colors 8Bit,16.7M
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption lower than 250W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor
    Working Temperature 0°C~50°C
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing



    LCD Video Wall Board Specifications

    Support PC Color 24bit
    Signal   Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ

    DVI

    HDMI

    DP

    Color 24bit
    Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ
    Interface Input VGA x 1 15pin D-Sub
    DVI x 1 DVI-I
    DP x 1 Display Port
    HDMI x 2 HDMI-19 pin
    Output PANEL LVDS 36Pin/2.0
    DP out DP loop out
    Power Input power DC24V/12V/5V
    Drive panel 5V/12V
    Power mode Normal working mode, power saving mode
    Other OSD Chinese, English and other languages (other languages can be added as required)



    Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall 0Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall 1Narrow Bezel 55 Inch Interactive Digital Wall , 60Hz 16dots Touch Screen Video Wall 2
