1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor

1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor

  • 1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor
  • 1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor
  • 1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor
1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor
Product Details:
Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: DDW-LW460HN13
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
Supply Ability: 3 , 000pcs per month
Contact Now
Detailed Product Description
Diagonal Size: 46" Total Physical Bezel: 1.7mm
Resolution: 1920*1080 Product Name: Interactive Video Wall
Panel Width: 1020.02 Mm Panel Height: 574.61 Mm
Backight System: LED Contrast: MEGA DCR
Highlight:

interactive video display

,

interactive wall display

LW460HN13 1.7mm Interactive Video Wall 1920*1080 700 nits 1020.02mm 574.61mm





Interactive Video Wall Features

  •  Support a variety of signal ports
  •  Built-in splicing module , Support splice function
  •  Support creating one window PIP across the screen , roaming service , scaling , PIP
  •  Support matrix joint control
  •  Unique DNX motion supplement image processing technology
  •  Dynamic image without motion trail
  •  Splicing image processing RS-232 RJ45 loop-circuit input/output
  •  Input by remote control with wire , mobile receiver head

Description

DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.



46inch Interactive Video Wall Parameters

  •  Original DDW commercial grade lcd video wall display panel  , 16:9 TFT-LCD
  •  700its brightness , MEGA DCR contrast.FHD video wall unit , high brightness , high contrast , high gamut
  •  FHD 1.7mm Ultra narrow bezel , high quality , practical , good vision effect
  •  Interface: 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output
  •  Flexible structure design , easy installation , extensible , arbitrary combination
  •  Stable performance , suitable working for a long time



Specifications

Model No. DDW-LW460HN13
Active Screen Diagonal 46''
Bezel Width Total: 1.7mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backight System LED
Luminance(nits) 700cd/sqm
Contrast MEGA DCR
Viewing Angle H 178°|V 178°
Panel Dimension(WxHxD) 1020.02×574.61x68.1mm
White Point 10,000 K
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000 h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption lower than 250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor
Working Temperature 0°C~50°C
Working Humidity 0.85
Storage Temperature -20-60°C | -4-140°F
Storage Humidity 85% non-condensing





Interactive Video Wall Board Specifications

Support PC Color 24bit
Signal   Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ

DVI

HDMI

DP

Color 24bit
Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ
Interface Input VGA x 1 15pin D-Sub
DVI x 1 DVI-I
DP x 1 Display Port
HDMI x 2 HDMI-19 pin
Output PANEL LVDS 36Pin/2.0
DP out DP loop out
Power Input power DC24V/12V/5V
Drive panel 5V/12V
Power mode Normal working mode, power saving mode
Other OSD Chinese, English and other languages (other languages can be added as required)





1.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor 01.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor 11.7mm Multi Screen Display Wall , 700 Nits Touch Screen Videowall With Motion Sensor 2
