Motion Sensor 55 20dots Capacitive Touch Video Wall Physical Resolution 1920*1080 TFT LCD

Motion Sensor 55 20dots Capacitive Touch Video Wall Physical Resolution 1920*1080 TFT LCD

  • Motion Sensor 55 20dots Capacitive Touch Video Wall Physical Resolution 1920*1080 TFT LCD
  • Motion Sensor 55 20dots Capacitive Touch Video Wall Physical Resolution 1920*1080 TFT LCD
  • Motion Sensor 55 20dots Capacitive Touch Video Wall Physical Resolution 1920*1080 TFT LCD
  • Motion Sensor 55 20dots Capacitive Touch Video Wall Physical Resolution 1920*1080 TFT LCD
Motion Sensor 55 20dots Capacitive Touch Video Wall Physical Resolution 1920*1080 TFT LCD
Product Details:
Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: DDW-LW550HN16
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: L/C , L/C , T/T
Supply Ability: 3 , 000pcs per month
Contact Now
Detailed Product Description
Product Name: Interactive Video Wall Type: TFT
Panel Size: 55 Inch Max Resolution: 1920x1080
Pixel Pitch: 0.63x0.63mm Contrast Ratio: 4000:1
Brightness: 500nits Response Time: 5ms
Highlight:

interactive video display

,

interactive touch screen video wall

55" Interactive Video Wall HD Physical Resolution 1920*1080 DDW-LW550HN16





Interactive Video Wall Quick Details

Input Voltage: AC 110-240V

Brightness: 500nits

Total bezel width: 1.7mm

Resolution: 1920*1080

Contrast: 4000:1

Surface: anti-glare

Video wall monitor power consummtion:250W

Application condition: indoor and semi-outdoor



55" high brightness LCD video wall features:

1, Original 55 inch DDW industrial grade LCD video wall panel,16:9 LG a-Si TFT-LCD

2, LED backlight 500nits high brightness

3, HD physical resolution 1920*1080

4, Only 1.7mm ultra narrow bezel.high quality ,Practical ,good vision effect.

5, Interface --- 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output

6, FHD video wall unit--- High brightness,high contrast,High gamut .

7, Flexible structure design ---easy installation ,extensible,arbitrary combination

8, Stable performance,suitable working for a long time



Applications

This 55inch 1.7mm narrow bezel video wall is the best cost-effective model , which can be widely used for cctv control room conference and meeting rooms , gym center , lobbies , security monitoring center , surveillance and retail center , restaurant and hotel , retail shopping mall advertising and information displays , public installations , exhibition and show center , live show , rental and advertising center , museums , church , transportation and mass info display systems.



LCD Video wall Panel Specifications

LCD Technology SAMSUNG DID LCD
Active Screen Diagonal 55"
Bezel Width Total: 1.7mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backight System LED
Luminance(nits) 500cd/sqm
Contrast MEGA DCR
Viewing Angle H 178°|V 178°
Pixel Pitch(WxH) 0.63×0.63mm
Active Display Area(WxH)

1209.6 × 680.4 mm

Panel Dimension(WxHxD) 1211.54×682.34x68.1mm
White Point 10,000 K
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000 h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption lower than 250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor
Working Temperature 0°C~50°C
Working Humidity 0.85
Storage Temperature -20-60°C | -4-140°F
Storage Humidity 85% non-condensing



LCD Video Wall Board Specifications

Support PC Color 24bit
Signal   Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ

DVI

HDMI

DP

Color 24bit
Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ
Interface Input VGA x 1 15pin D-Sub
DVI x 1 DVI-I
DP x 1 Display Port
HDMI x 2 HDMI-19 pin
Output PANEL LVDS 36Pin/2.0
DP out DP loop out
Power Input power DC24V/12V/5V
Drive panel 5V/12V
Power mode Normal working mode, power saving mode
Other OSD Chinese, English and other languages (other languages can be added as required)





Packaging & Delivery

Packaging Details: quality carton with full wood box packing

Delivery Detail: 3 working days
