    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW550HN11

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Video Wall Display Systems Color: 8Bit , 16M
    Aspect Ratio: 16:9 Panel Width: 1213.5 Mm
    Panel Height: 684.3 Mm Screen: 9 Screen
    White Point: 10,000 K Control: Remote Control
    High Light:

    broadcast video wall

    ,

    control room displays

    9 Screen Video Wall Display Systems / Remote Control Room Displays



    Our Service


    Our customizable solutions offer a range of user-friendly features that streamline operation and enable the interconnectivity of your corporate control room, meeting rooms, and multi-screen display systems. Integrating a range of content types and signal formats, DDW’s multi screen video wall, control room display and digital signage systems can help you get your message across to customers more effectively.


    DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.



    Video Wall Display Systems parameters

    1. Original DDW commercial grade lcd video wall display panel,16:9 LG a-Si TFT-LCD

    2. 500nits brightness,MEGA DCR contrast.HD video wall unit--- High brightness,high contrast,High gamut .

    3. FHD physical resolution 1920x1080

    4. Only 3.5mm ultra narrow bezel, high quality ,practical ,good vision effect.

    5. Interface--- 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output



    Video Wall Display Systems features:



    1. Support a variety of signal ports.

    2. Built-in splicing module, Support splice function

    3. Support creating one window PIP across the screen, roaming service, scaling,PIP

    4. Support matrix joint control.

    5. Unique DNX motion supplement image processing technology,

    6. Dynamic image without motion trail



    Video Wall Display Systems Specifications



    Model No: DDW-LW550HN11 Video Wall Display Systems
    Active Screen Diagonal 55''
    Total Bezel Width 3.5 mm
    Aspect Ratio 16:9
    Physical Resolution 1920x1080
    Backight System LED
    Luminance(nits) 500cd/㎡
    Contrast 5000:1
    Viewing Angle H 178°|V 178°
    Panel Dimension(WxHxD)

    1213.5mmx684.3mmx67.7mm

    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption ≦160W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor
    Working Temperature 0℃~50℃
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing



    Video Wall Display Systems Board Specifications



    Support PC Color 24bit
    Signal   Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ

    DVI

    HDMI

    DP

    Color 24bit
    Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ
    Interface Input VGA x 1 15pin D-Sub
    DVI x 1 DVI-I
    DP x 1 Display Port
    HDMI x 2 HDMI-19 pin
    Output PANEL LVDS 36Pin/2.0
    DP out DP loop out
    Other OSD Chinese, English and other languages (other languages can be added as required)



    9 Screen Video Wall Display Systems / Remote Control Room Displays 0
