49" Video Wall Display Monitors , High Color Gamut Security Video Wall

49" Video Wall Display Monitors , High Color Gamut Security Video Wall

    • 49" Video Wall Display Monitors , High Color Gamut Security Video Wall
  • 49" Video Wall Display Monitors , High Color Gamut Security Video Wall

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW490DUN-THC1

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Size: 49" Surface: Anti-glare
    Product Name: Video Wall Display Monitors Backlight: LED
    Color: 8Bit , 16M Working Humidity: 0.85
    Advantage: High Color Gamut MTBF: > 100,000 H
    High Light:

    broadcast video wall

    ,

    control room displays

    49" Video Wall Display Monitors , High Color Gamut Security Video Wall



    Video Wall Display Monitors Introduction



    Video Wall Display Monitors technology is a high quality image representative of serial transmission, mainly used in some professional field of television and radio and television, the product supports audio embedded solution, at the same time, supports the highest resolution to 1080p 60Hz, which should be more extensive.



    Video Wall Display Monitors features:



    1. Support a variety of signal ports.

    2. Built-in splicing module, Support splice function

    3. Support creating one window PIP across the screen, roaming service, scaling,PIP

    4. Support matrix joint control.

    5. Unique DNX motion supplement image processing technology,



    Video Wall Display Monitors Specifications:



    Model No: DDW-LW49DUN-THC1 Video Wall Display Monitors
    LCD Technology LG IPS LCD
    Active Screen Diagonal 49"
    Total Bezel Width 3.5mm
    Aspect Ratio 16:9
    Physical Resolution 1920x1080
    Backight System LED
    Luminance(nits) 500cd/sqm
    Contrast MEGA DCR
    Viewing Angle H 178°|V 178°
    Pixel Pitch(WxH)

    0.5593x0.5593mm

    Active Display Area(WxH) 1073..8×604 mm
    Panel Dimension(WxHxD) 1077.6×607.8x55.6mm
    White Point 10,000 K
    Maximum Power Consumption lower than 250W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor
    Working Temperature 0°C~50°C
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing



    Video Wall Display Monitors Board Specifications



    Support PC Color 24bit
    Signal   Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ

    DVI

    HDMI

    DP

    Color 24bit
    Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ
    Interface Input VGA x 1 15pin D-Sub
    DVI x 1 DVI-I
    DP x 1 Display Port
    HDMI x 2 HDMI-19 pin
    Output PANEL LVDS 36Pin/2.0
    DP out DP loop out
    Other OSD Chinese, English and other languages (other languages can be added as required)



    49" Video Wall Display Monitors , High Color Gamut Security Video Wall 0
