Name: Samsung Panel Seamless LCD Video Wall , Colorful 55 Video Wall Display
Brand: Shenzhen DDW Technology Co., Ltd.
SKU: DDW-LW550HN14
Availability: InStock

Home Products LCD Video Wall Display

Samsung Panel Seamless LCD Video Wall , Colorful 55 Video Wall Display

Product Details:

Place of Origin:	Guangdong , China (Mainland)
Brand Name:	DDW
Certification:	ISO9001 , CE , RoHS , FCC
Model Number:	DDW-LW550HN14

Payment & Shipping Terms:

Minimum Order Quantity:	2pcs
Price:	Negotiable
Packaging Details:	First layer carton pack with filling foam , then wood pallet pack
Delivery Time:	3 working days upon payment
Payment Terms:	T/T , Western , L/C Union , Alibaba trade assurance
Supply Ability:	3 , 000pcs per month

Contact Now

Detailed Product Description

Name:	Seamless LCD Video Wall	Size:	55 Inch
Panel Brand:	Samsung	Active Area:	1209.6 × 680.4 Mm
Refresh Rate:	60Hz	White Point:	10,000 K
Working Temperature:	0°-50°C	Contrast:	MEGA DCR
Highlight:	ultra narrow bezel video wall , video wall lcd screens

Samsung Panel Seamless LCD Video Wall , Colorful 55 Video Wall Display

Seamless LCD Video Wall Key features:

Support creating one window PIP across the screen, roaming service, scaling,PIP
Support matrix joint control.
Unique DNX motion supplement image processing technology,
Dynamic image without motion trail
Splicing image processing RS-232 RJ45 loop-circuit input/output.

Seamless LCD Video Wall main parameters

1 FHD physical resolution 1920x1080

2 Only 1.7mm ultra narrow bezel, high quality ,practical ,good vision effect.

3 Interface--- 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output

4 HD video wall unit--- High brightness,high contrast,high gamut .

Seamless LCD Video Wall Application

CCTV control room conference and meeting rooms
gym center
lobbies
security monitoring center
surveillance and retail center

Seamless LCD Video Wall Specifications:

Name:	Seamless LCD Video Wall	Size:	55 Inch
Panel Brand:	Samsung	Active Area:	1209.6 × 680.4 Mm
Refresh Rate:	60Hz	White Point:	10,000 K
Working Temperature:	0°-50°C	Contrast:	MEGA DCR

Seamless LCD Video Wall Board Specifications

Support	PC	Color	24bit
Signal		Line synchronization range	30-80KHZ
		Field synchronization range	50-75HZ
	DVI HDMI DP	Color	24bit
		Line synchronization range	30-80KHZ
		Field synchronization range	50-75HZ
Power	Input power	DC24V/12V/5V
	Drive panel	5V/12V
	Power mode	Normal working mode, power saving mode
Other	OSD	Chinese, English and other languages (other languages can be added as required)
