Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor

Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor

    • Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor
    • Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor
    • Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor
  • Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor

    Product Details:

    Place of Origin: Guangdong, China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 ,CE , RoHS , FCC , 3C
    Model Number: DDW-VPH0404

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Unit/Units
    Price: Negotiable
    Packaging Details: Double layer carton pack
    Delivery Time: 3working days upon payment
    Payment Terms: T/T,L/C,Western Union,Alibaba Trade Assurance
    Supply Ability: 1000pcs/month
    Contact Now
    Detailed Product Description
    Signal Input: 4 X HDMI Signal Output: 4 X HDMI
    Roam,zoom,PIP: Support Color Quality: 32bit
    SDI: BNC Port Control Method: RS232,IP
    Product Name: Video Wall Processor Application: Public Security
    High Light:

    multi display processor

    ,

    video display wall controller

    4x4 HDMI Video Wall Processor For Control Room Surveillance Center CCTV


    Video Wall Processor Key Features:
    1. Full hardware configuration without operating system
    2. High-speed bus parallel processing technology, high-bandwidth uncompressed processing
    3. Real time image display, no dropped frames
    4. Flexibility to increase the input/output board
    5. Support partial input and output cards with mixed interpolation
    6. Input/output card supports hot-swappable, plug-and-play functionality
    7. Output resolution up to 1920 x 1200
    8. Rich BNC, VGA, DVI, HDMI, SDI and RJ45 input interface, support for multiple resolutions up to 1920x1200,control via RS-232 or Ethernet
    9. Support memory card or network transmission ultra-high-definition pictures, peer-to-peer ultra-high-definition mosaic wall background image
    10. Redundant power supply design, thermostatically controlled fan
    11. Chassis backplane + plug-in configuration, excellent performance for radiating, anti-dust chassis, equipped with replaceable air filter can be stable for a long time, even in harsh environments



    Video Wall Processor Simplified installation & disassembly

    •  Flexible modular design, Input and output card board;
    •  Support input of a variety of interfaces and signal source;
    •  Matching features, pre-monitoring;
    •  Echo function, input and output characters display with superimposed;

    Pure hardware architecture board any combination:

    •  Industrial chassis with CPCI structure;
    •  Modular design, dual backup redundant power supply support hot backup, fan and other modules at will;
    •  Supporting the system processing module hot-swappable, provide various types of chassis and board, for customers to save costs;


    DDW Video Wall Processor Technical Specifications

    Model series With CBD Function No CBD
    Function description

    4channel CBD,16channel AV, 12channel VGA/DVI input, 6U case supports 12 screens arrays, compatible with ultra-high resolution 4000/(8000)x2000 Dynamic background image

    ~ 16channel AV,16channel VGA/ DVI input,6U case supports 16screens arrays
    Input signal(optional) CVBS Support PAL/NTSC format, multiple BNC ports ~
    VGA/RGBHV Multi-channel VGA DB-15 ports, support VGA full-format input ~
    HDMI, DVI, 4K-DVI, IP Support 4K(3840x2160) input, each IP decode 4 channels ~
    YPbPr, YCbCr(customizable) The same connector of VGA, RGBHV signal, support PAL, NTSC format and 720P, 1080i HSTV ~
    SDI(customizable) BNC Port ~
    AV, SD/HD/3G SDI, IP decoding, optical fiber, DP, HDBaseT, Preview monitoring card can be customized; ~ ~
    Input resolution up to 4K,commonly used resolutions
    Output signal format VGA, RGBHV signal channel XGA(1024x768@60Hz)/DB-15 port ~
    HDMI, DVI, 4K-DVI HDMI, DVI output ~
    3G SDI(customzable) BNC Port loop out ~
    AV, YPbPr,DVI-HDMI converter, SD, HD, DP, HDBaset can be customized; ~ ~
    Output resolution up to 4K,commonly used resolutions
    Control Standard RS232 port
    IR remote control(customzable), LAN contril, IOS, Android APP control( optional)
    System control software Special control software
    Power Supply Redundant power supply 110-220VAC, 50/60Hz
    Consumption 12W/channel
    Working temperature -20°C——60°C
    Working Humidity 5-95%
    Case specification 2U, 3.5U, 7U,10U, 12.5U, 15U, 23U standard rackmount chassis
    Serial Control Interface RS-232,9-pin female, Type-D
    Baud Rate 115200
    Pin configuration 2=TX,3=RX,5=GND
    Ethernet control interface RJ-45 female, TCP/IP
    Ethernet control speed Auto 10M or 100M,Full-duplex or half-duplex
    Working time 365x7x24hrs



    Hareware video wall controller U Chassis Specs

    Chassis U size Controller Dims(mm)
    L*W*H
    Pack dims(mm)
    L*W*H
    N.W(kg) G.W(kg) Max input Nos. Max output Nos. Max Power Consumption(Watts)
    2U 406×440×102 590×530×190 11.25 12.25 8 8 200
    3.5U 450x440x170 620x620x270 18.25 19.25 16 16 320
    7U 442×402×320 590×530×460 29.5 31.50 32 32 400
    12.5U 446×440×553 625×580×725 37.85 39.85 71 68 750
    23U 442×43×1022 615×570×1180 80.46 82.46 143 140 1300


    Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor 0Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor 1Control Room Display Wall Controller , Surveillance Center 4x4 HDMI Multi Display Processor 2
