Horizontal Seamless Video Wall Displays / Multi LCD Wall Display Screen

Horizontal Seamless Video Wall Displays / Multi LCD Wall Display Screen

    • Horizontal Seamless Video Wall Displays / Multi LCD Wall Display Screen
  • Horizontal Seamless Video Wall Displays / Multi LCD Wall Display Screen

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW460HN14

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Type: Horizontal Product Name: Seamless Video Wall Displays
    Backlight: LED Resolution: 1920*1080
    Input Voltage: AC 220v-250v Total Physical Bezel: 1.7mm
    Refresh Rate: 60Hz White Point: 10,000 K
    High Light:

    lcd screen wall


    seamless lcd video wall

    Horizontal Seamless Video Wall Displays / Multi LCD Wall Display Screen


    Seamless Video Wall Displays Main features:


    1. Samsung industrial panel, support 24 hours continously playing;
    2. The gaps between panels is 5.3mm;
    3. Full hardware structure, no CPU and operation system;
    4. Easy installation, only fixed them together by metal bracket ;
    5. Easy operation , can operate the system together with the software flexible,we offer free software;
    6. Support RS-232 serial ports remote control;
    7. Support multi signal input include BNC, YPbPr,VGA,HDMI,RS232;
    8. Images are displayed smoothly and naturally without time delay and tailing, and the image quality are quite smoothy.


    Seamless Video Wall Displays main parameters


    1. Original DDW commercial grade lcd video wall display panel

    2. 500 nits brightness,MEGA DCR contrast

    3. FHD physical resolution 1920x1080

    4. Only 1.7 mm ultra narrow bezel, high quality ,Practical ,good vision effect.

    5. Interface --- 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output

    6. HD video wall unit--- High brightness,high contrast,High gamut .

    7. Flexible structure design ---easy installation ,extensible,arbitrary combination

    8. Stable performance,suitable working for a long time


    Seamless Video Wall Displays Key features:

    1. Support a variety of signal ports.

    2. Built-in splicing module, Support splice function

    3. Support creating one window PIP across the screen, roaming service, scaling,PIP

    4. Support matrix joint control.

    5. Unique DNX motion supplement image processing technology,

    6. Dynamic image without motion trail

    7. Splicing image processing RS-232 RJ45 loop-circuit input/output.

    8. Input by remote control with wire, mobile receiver head.


    Seamless Video Wall Displays Specifications:


    Model No: DDW-LW460HN14
    Active Screen Diagonal 46"
    Total Bezel Width 1.7 mm
    Aspect Ratio 16:9
    Physical Resolution 1920x1080
    Backight System LED
    Luminance(nits) 500 cd/sqm
    Contrast MEGA DCR
    Viewing Angle H 178°|V 178°
    Dot Pitch


    Panel Dimension(WxHxD)


    White Point 10,000 K
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption lower than 250W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor
    Working Temperature 0°C~50°C
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing


    Seamless Video Wall Displays Board Specifications


    Support PC Color 24bit
    Signal   Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ




    Color 24bit
    Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ
    Interface Input VGA x 1 15pin D-Sub
    DVI x 1 DVI-I
    DP x 1 Display Port
    HDMI x 2 HDMI-19 pin
    Output PANEL LVDS 36Pin/2.0
    DP out DP loop out
    Power Input power DC24V/12V/5V
    Drive panel 5V/12V
    Power mode Normal working mode, power saving mode
    Other OSD Chinese, English and other languages (other languages can be added as required)




    1. Q: Are you a manufacturer or trading company?
    A:We are a manufacturer who has been specializing in producing LCD display for years.


    2. Q: How does your factory do regarding quality control?
    A:Quality is priority.DDW people always attach great importance to quality controlling from the

    very beginning to the very end. We focus on every detail ,Our factory has gained ISO9001, ISO14001, CE, RoHS authentication.


    3. Q: What is your after-sale service?
    A: We offer 100% guarantee on our product .


    4. Q: What is your MOQ?
    A: Any quantity is acceptable for your order. And the price is negotiable for large quantity.

    5. Q: When will you make the delivery?
    A: We can make the delivery within 3-15 working days according to the size and quantities
    of your order.

    6.Q:what brand of screen are you using?
    A:we are using Samsung,LG,AUO and CHIMEI screen.
