Ultra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video Wall

Ultra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video Wall

    • Ultra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video Wall
    • Ultra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video Wall
    • Ultra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video Wall
  • Ultra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video Wall

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LEDP6

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: LED Video Wall Display Feature: Energy Saving
    Pixel Pitch: 6.0mm Working Humidity: 10%-95%RH
    IP Grade: IP65 Panel Type: Steel Cabinet
    Maitainence Mode: Rear Maitainence Refresh Rate: ≥1920Hz

    Ultra Light Fixed LED Video Wall Display High Precision Super Slim Front Water Proof





    LED Video Wall Display​​ Introduction

    •  Ultra-light---lighter 40% than aluminum die-csting cabinet.

    •  High precision---seamless splicing though CNC machining.

    •  Super slim---high-strength,more slim than aluminum in the design,thiner around 30%.

    •  Easy installation---installed by quick lock for 20s only.

    IP65 front Water proof

    High protection grade of IP65 guarantees,Durability, Reliability, Anti-ultraviolet and Steady.



    Dual channel heat dissipation

    Low power consumption and fast heat dissipation/ energy saving and environment protection.



    Super wide angle

    Wide Viewing Angle can achieve to Vertical viewing 150 Horizontal viewing 120.



    LED video wall is any large electronic display of an image or images being displayed in a presentation format. Typically multiple display devices are tiled together as close as possible in a matrix to create a single logical screen (The Video Wall). Then with special Video Processor devices, an image is scaled across the logical screen or multiple images are spread out over the logical screen or a combination of both in the case of picture in picture. This is all without respect for the individual display devices physical boundaries.



    LED Video Wall Display Specification

    Pixel Configuration SMD2727
    Pixel Pitch(mm) 6.0
    Pixel Density(dot/m2) 27777
    Module Pixel Matrix (W×H) 32×32
    Module Size(mm) 192(W)×192(H)
    Module Weight(kg) 0.6
    Module Power Consumption Max.(W) 30
    Module/Panel(W×H) 5x5
    Panel Resolution(W×H) 160×160
    Panel Size(mm) 960(W)×960(H)×160(D)
    Panel Weight(kg) 35
    Maitainence Mode Rear Maitainence
    Panel type Steel cabinet
    Brightness(nits) ≥5200
    Color Temperature(K) 3200—9300
    Viewing Angle(Hor/Vert°) 140/120
    Power Consumption Max(W/m2) 1000
    Power Consumption Avg(W/m2) 200-300
    Operating Power Source AC90~264V,Frequency 47-63(Hz)
    Frame Frequency(Hz) 50&60
    Drice Mode Constant Driving,1/8S
    Gray Scale 65536
    Refresh Rate(Hz) ≥1920
    Gray Scale per Color Level 16bit
    Working Temperature/Humidity(℃/RH) -20 – 60 / 10%-85%RH
    Storage Temperature/Humidity(℃/RH) -20 – 60 / 10%-85%RH



    Ultra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video WallUltra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video WallUltra Light Fixed High Resolution LED Display , Front Water Proof Indoor LED Video Wall
