Anti - Glare Surface Curved Video Wall 55 Inch 3.5 Mm Seamless With DP Loop In Loop Out

Anti - Glare Surface Curved Video Wall 55 Inch 3.5 Mm Seamless With DP Loop In Loop Out

    • Anti - Glare Surface Curved Video Wall 55 Inch 3.5 Mm Seamless With DP Loop In Loop Out
    • Anti - Glare Surface Curved Video Wall 55 Inch 3.5 Mm Seamless With DP Loop In Loop Out
    • Anti - Glare Surface Curved Video Wall 55 Inch 3.5 Mm Seamless With DP Loop In Loop Out
  • Anti - Glare Surface Curved Video Wall 55 Inch 3.5 Mm Seamless With DP Loop In Loop Out

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW550HN11

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Bezel Width: 3.5 Mm Surface: Anti-glare
    Brightness: 500 Nits Product Name: Curved Video Wall
    Color: 8Bit , 16M Aspect Ratio: 16:9
    Panel Brand: SAMSUNG Heat Dissipation: 819 BTU/h (max)
    High Light:

    curved lcd video wall

    ,

    curved display wall

    SAMSUNG LW550HN11 Curved Video Wall 55 inch 3.5 mm seamless 0.63x0.63 mm Dot Pitch




    Curved LCD video wall basic informations:

    •  With original LG, Samsung panel, has a stylish design, lighter weight, easy to handle and install;
    •  Adapting modular components, making maintenance operations and parts replacement very easily;
    •  The installation method: floor standing cabinets;
    •  Dot Pitch: 0.63mm(H)*0.63mm(W); Contrast ratio: 4000:1; Responsive time: 6ms;
    •  Panel life: above 50000 hours; Certificate: FCC, CE, ROHS, IP65; Warranty: 1 year;
    •  7x24x365 keep working;

    Curved LCD video wall key features:

    •  Panel size: 46″, 49″, 55″, 60″ Optional.
    •  Ultra narrow frame design, the narrowest bezel is 3.5 mm and the bezel can be optional.
    •  Wall mounted, floor standing, floor standing cabinets and front push hydraulic Pop out optional.
    •  The front: the shell adopting black matt anti magnetic unique and exquisite strong in anti interferce;
    •  2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output
    •  Accessories: English manual, hanger, RS232-RJ45 converter, English IR controller, RJ45 cables, software USB sticker
    •  Working Temperature: 0°C~50°C.Working Humidity: 20%-80%;
    •  Application areas: real estate sale center, clothing store, ticketing center, hotel lobby, mobile phone shop, restaurant;



    Specifications:

    Model No: DDW-LW550HN11
    LCD Technology SAMSUNG LCD
    Active Screen Diagonal 55''
    Total Bezel Width 3.5 mm
    Aspect Ratio 16:9
    Physical Resolution 1920x1080
    Backight System LED
    Luminance(nits) 500 cd/sqm
    Contrast MEGA DCR
    Viewing Angle H 178°|V 178°
    Panel Dimension(WxHxD)

    1213.5x684.3x67.7 mm

    White Point 10,000 K
    Display Colors 8Bit,16.7M
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption lower than 250W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor
    Working Temperature 0°C~50°C
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing



    Curved LCD Video Wall Board Specifications

    Support PC Color 24bit
    Signal   Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ

    DVI

    HDMI

    DP

    Color 24bit
    Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ
    Interface Input VGA x 1 15pin D-Sub
    DVI x 1 DVI-I
    DP x 1 Display Port
    HDMI x 2 HDMI-19 pin
    Output PANEL LVDS 36Pin/2.0
    DP out DP loop out
    Power Input power DC24V/12V/5V
    Drive panel 5V/12V
    Power mode Normal working mode, power saving mode
    Other OSD Chinese, English and other languages (other languages can be added as required)
