High Brightness Mosaic Video Wall / Super Narrow Bezel Video Wall Display

High Brightness Mosaic Video Wall / Super Narrow Bezel Video Wall Display

    • High Brightness Mosaic Video Wall / Super Narrow Bezel Video Wall Display
  • High Brightness Mosaic Video Wall / Super Narrow Bezel Video Wall Display

    Product Details:

    Place of Origin: Guangdong, China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW550HN16

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: Negotiation
    Packaging Details: Quality carton with full wood box packing
    Delivery Time: 3 working days upon payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Name: Mosaic Video Wall Feature: High Brightness
    Application: Indoor, Semi-outdoor Viewing Angle: 178°/178°
    Contrast Ratio: 4000:1 Brightness: 350-700 Nits
    Response Time: 6ms Input Voltage: 220V
    High Light:

    art video wall

    ,

    artistic video wall

    High Brightness Mosaic Video Wall / Super Narrow Bezel Video Wall Display



    Mosaic Video Wall Quick Details



    Application:Indoor, semi-outdoor

    Viewing Angle:178°/178°

    Contrast Ratio:4000:1

    Brightness:350-700nits

    Response Time:6ms

    Input Voltage:220V

    Warranty:1 Year, 1 Year

    After-sales Service Provided:Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Online support

    Usage:Indoor

    Display Function:Video

    Installation:wall mounted/ floor standing

    Screen Dimension:1211.6x682.4x38.7mm

    Operating system:Android Network /Standalone /PC version



    Mosaic Video Wall Parameters:



    Name High Brightness Mosaic Video Wall / Super Narrow Bezel Video Wall Display
    Item No. Components Descriptions
    1 55" Samsung 1.7mm bezel 500nits brightness,WLED Backlit,1920x1080 resolution,with 1080P HDMI input
    2 System controller 1 in 16output HDMI splitter
    3 Bracket POP out bracket for 55" lcd video wall
    4 Standard Accessories IR Controller,Power Cables,RJ45 Cables,RS232-RJ45 Connector
    5 Packing 4/5 screens in 1 wooden case
    Panel Specifications
    LCD Technology Original Samsung DID LCD
    Active Screen Diagonal 55"
    Panel Dimension(WxH) 1211.6*682.4mm
    Total Bezel Width 1.7mm
    Aspect Ratio 16:9
    Physical Resolution 1920*1080
    Backlight System WLED
    Luminance(nits) 500cd/m2
    Contrast 1500:1 (typ.)
    Viewing Angle H 178°|V 178°
    Display Colors 8Bit,16.7M
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption <=260W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Working Time Capacity 7x24x365hours
    Working Temperature 0℃~50℃
    Working Humidity 0.85
    Storage Temperature -20-60°C | -4-140°F
    Storage Humidity 85% non-condensing
    Net Weight 26kg/unit



    Packaging & Delivery



    Selling Units:Single item

    Single package size: 110X20X80 cm

    Single gross weight:32.0 kg

    Package Type:Quality carton with full wood box packing



    Lead Time :



    Quantity(Piece) 1 - 50 51 - 100 >100
    Est. Time(days) 3 5 To be negotiated
