Ultra Narrow Bezel 55 Inch Video Wall / Security CCTV Monitor Wall Mounted

China Ultra Narrow Bezel 55 Inch Video Wall / Security CCTV Monitor Wall Mounted supplier

Large Image :  Ultra Narrow Bezel 55 Inch Video Wall / Security CCTV Monitor Wall Mounted

Product Details:

Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: DDW-LW550DUN-TKB1

Payment & Shipping Terms:

Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
Supply Ability: 3 , 000pcs per month
Contact Now
Detailed Product Description
Product Name: 55 Inch Video Wall Display Colors: 8Bit,16.7M
Power Supply: AC100~240V 50/60 HZ Bezel: Ultra Narrow Bezel
Usage: Security Surface: Anti-glare
Height: 684.2mm Size: 55 Inch

Ultra Narrow Bezel 55 Inch Video Wall / Security CCTV Monitor Wall Mounted



55 Inch Video Wall features:



1. Built-in splicing module, Support splice function

2. Unique DNX motion supplement image processing technology,

3. Dynamic image without motion trail

4. Splicing image processing RS-232 RJ45 loop-circuit input/output.

5. Input by remote control with wire, mobile receiver head.



55 Inch Video Wall parameters

  •  FHD physical resolution 1920x1080
  •  Only 3.5 mm ultra narrow bezel, high quality ,practical ,good vision effect.
  •  2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output
  •  FHD video wall unit--- High brightness,high contrast,high gamut .
  •  Flexible structure design ---easy installation ,extensible,arbitrary combination
  •  Stable performance,suitable working for a long time

55 Inch Video Wall  Specifications



Model No:

DDW-LW550DUN-TKB1

LCD Technology LG TFT-LCD
Active Screen Diagonal 55"
Pixel Pitch(WxH) 0.630x0.630mm
Active Display Area(WxH) 1209.6x680.4mm
Panel Dimension(WxHxD)

1213.4x684.2x38.9mm

Total Bezel Width 3.5 mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backlight System LED
Luminance(nits) 500 cd/sqm
Contrast 5000:1 (typ.)
Viewing Angle H 178°|V 178°
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption <=250W
Power Supply AC100~240V 50/60 HZ
Working Humidity 85% non-condensing
Storage Temperature -20-60°C | -4-149°F
Storage Humidity 85% non-condensing



CCTV Video Wall​ Board Specification

Support PC color 24bit
signal   Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ
DVI color 24bit
HDMI Line synchronization range 30-80KHZ
DP Field synchronization range 50-75HZ
Interface input VGA x 1 15pin D-Sub
DVI x 1 DVI-I
DP x 1 Display Port
HDMI x 2 HDMI-19 pin
output PANEL LVDS 36Pin/2.0
DP out DP loop out
Power Input power DC24V/12V/5V
Drive panel 5V/12V
Power mode Normal working mode, power saving mode
Other OSD Chinese, English and other languages (other languages can be added as required)





Ultra Narrow Bezel 55 Inch Video Wall / Security CCTV Monitor Wall Mounted
