Flashing Advertising Signs CCTV Video Wall With Wall Mounted Bracket

China Flashing Advertising Signs CCTV Video Wall With Wall Mounted Bracket supplier

Large Image :  Flashing Advertising Signs CCTV Video Wall With Wall Mounted Bracket

Product Details:

Place of Origin: Guangdong , China (Mainland)
Brand Name: DDW
Certification: ISO9001 , CE , RoHS , FCC
Model Number: DDW-LW550HN14

Payment & Shipping Terms:

Minimum Order Quantity: 2pcs
Price: Negotiable
Packaging Details: First layer carton pack with filling foam , then wood pallet pack
Delivery Time: 3 working days upon payment
Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
Supply Ability: 3 , 000pcs per month
Contact Now
Detailed Product Description
Brightness: 700 Nits Product Name: CCTV Video Wall
Application: Flashing Advertising Signs Resolution: 1920*1080
Feature: Wall Mounted Bracket Total Physical Bezel: 1.7mm
Refresh Rate: 60Hz Panel Brand: SAMSUNG Panel

Flashing Advertising Signs CCTV Video Wall With Wall Mounted Bracket



CCTV Video Wall informations:

  •  Adapting modular components, making maintenance operations and parts replacement very easily;
  •  The installation method: floor standing;
  •  Panel life: above 50000 hours; Certificate: FCC, CE, ROHS, IP65; Warranty: 1 year;
  •  7x24x365 keep working;

CCTV Video Wall parameters



1. Original DDW commercial grade lcd video wall display panel

2. 700 nits brightness,MEGA DCR contrast

3. FHD physical resolution 1920x1080

4. Only 1.7mm ultra narrow bezel, high quality ,practical ,good vision effect.

5. Interface --- 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output



CCTV Video Wall features:



1. Support a variety of signal ports.

2. Built-in splicing module, Support splice function

3. Support creating one window PIP across the screen, roaming service, scaling,PIP

4. Support matrix joint control.

5. Unique DNX motion supplement image processing technology,



CCTV Video Wall ​Specifications:



Model No: DDW-LW550HN14 CCTV Video Wall
LCD Technology

SAMSUNG IPS LCD

Total Bezel Width 1.7 mm
Aspect Ratio 16:9
Physical Resolution 1920x1080
Backight System LED
Luminance(nits) 700 cd/sqm
Contrast MEGA DCR
Viewing Angle H 178°|V 178°
Panel Dimension(WxHxD)

1211.54×682.34x65.1mm

White Point 10,000 K
Display Colors 8Bit,16.7M
Refresh Rate 60Hz
Response Time <=6ms
Life(hrs) >60,000(hrs)
MTBF > 100,000 h
Surface Anti-glare
Standby Power Consumption <3W
Maximum Power Consumption lower than 250W
Power Supply AC100~240V 50/60 HZ
Cooling Low noise fans
Heat Dissipation 819 BTU/h (max)
Working Time Capacity 7x24x365hours
Application Area Indoor/Semi Outdoor
Working Temperature 0°C~50°C
Working Humidity 0.85
Storage Temperature -20-60°C | -4-140°F
Storage Humidity 85% non-condensing



CCTV Video Wall ​Board Specifications

Support PC Color 24bit
Signal   Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ

DVI

HDMI

DP

Color 24bit
Line synchronization range 30-80KHZ
Field synchronization range 50-75HZ
Power Input power DC24V/12V/5V
Drive panel 5V/12V
Power mode Normal working mode, power saving mode
Other OSD Chinese, English and other languages (other languages can be added as required)



Flashing Advertising Signs CCTV Video Wall With Wall Mounted Bracket
