Commercial Display CCTV Video Wall With Original Samsung Display Panel

Commercial Display CCTV Video Wall With Original Samsung Display Panel

    • Commercial Display CCTV Video Wall With Original Samsung Display Panel
  • Commercial Display CCTV Video Wall With Original Samsung Display Panel

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW460HN13

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Diagonal Size: 46 Inch Total Physical Bezel: 1.7mm
    Resolution: 1920*1080 P Product Name: CCTV Video Wall
    Panel: Samsung Display Panel Panel Height: 574.61 Mm
    Backight System: LED Contrast: MEGA DCR
    High Light:

    broadcast video wall

    ,

    control room displays

    Commercial Display CCTV Video Wall With Original Samsung Display Panel



    CCTV Video Wall​ Description



    DDW offers a range of scalable connectivity and display processing systems for corporate av applications, as well as large-scale multiscreen video wall solutions for enterprise-level installations. The remote capabilities and real-time signal processing provided by our conference, board, collaboration and control room display systems support multi-site workflows and critical decision-making.



    CCTV Video Wall​  Parameters

    •  700its brightness , MEGA DCR contrast
    •  FHD 1.7mm ultra narrow bezel , high quality , practical , good vision effect
    •  Interface: 2 x HDMI input, DVI input, VGA input, AV input, DP loop in loop out, RS232 input output
    •  FHD video wall unit , high brightness , high contrast , high gamut
    •  Flexible structure design , easy installation , extensible , arbitrary combination
    •  Stable performance , suitable working for a long time

    CCTV Video Wall Specifications



    Model No. DDW-LW460HN13
    Panel Specifications
    LCD Technology SAMSUNG TFT-LCD(NO. LW460HN13)
    Active Screen Diagonal 46"
    Bezel Width Total: 1.7mm
    Aspect Ratio 16:9
    Physical Resolution 1920x1080
    Backight System LED
    Luminance(nits) 700cd/sqm
    Contrast MEGA DCR
    Viewing Angle H 178°|V 178°
    Panel Dimension(WxHxD) 1020.02×574.61x68.1mm
    White Point 10,000 K
    Display Colors 8Bit,16.7M
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000 h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption lower than 250W
    Storage Humidity 85% non-condensing



    CCTV Video Wall​ Board Specifications

    Support PC Color 24bit
    Signal   Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ

    DVI

    HDMI

    DP

    Color 24bit
    Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ
    Interface Input VGA x 1 15pin D-Sub
    DVI x 1 DVI-I
    DP x 1 Display Port
    HDMI x 2 HDMI-19 pin
    Output PANEL LVDS 36Pin/2.0
    DP out DP loop out
    Other OSD Chinese, English and other languages (other languages can be added as required)

    Commercial Display CCTV Video Wall With Original Samsung Display Panel 0
