Home ProductsCommercial Video Wall

Remote Control Commercial Video Wall Beautiful Wall Structure Design

Remote Control Commercial Video Wall Beautiful Wall Structure Design

    • Remote Control Commercial Video Wall Beautiful Wall Structure Design
  • Remote Control Commercial Video Wall Beautiful Wall Structure Design

    Product Details:

    Place of Origin: Guangdong , China (Mainland)
    Brand Name: DDW
    Certification: ISO9001 , CE , RoHS , FCC
    Model Number: DDW-LW460HN12

    Payment & Shipping Terms:

    Minimum Order Quantity: 2pcs
    Price: Negotiable
    Packaging Details: First layer carton pack with filling foam , then wood pallet pack
    Delivery Time: 3 working days upon payment
    Payment Terms: T/T , Western , L/C Union , Alibaba trade assurance
    Supply Ability: 3 , 000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Commercial Video Wall Control: Remote Control
    Display Colors: 8Bit,16.7M Power Supply: AC100~240V 50/60 HZ
    Cooling: Low Noise Fans Total Physical Bezel: 3.5mm
    Surface: Anti-glare Design: Beautiful Wall Structure Design
    High Light:

    multi display video wall

    ,

    lcd screen wall

    Remote Control Commercial Video Wall Beautiful Wall Structure Design



    Commercial Video Wall Functions



    1. Narrow design: the narrowest can reach 3.5mm, and it truly achieves the seamless.
    2. Interface type: VGA, DVI connected analog signal and digital high-definition signal
    3. Remote control function: by RS232 port and Ethernet connection for remote operation
    4. Beautiful wall structure design, be convenient for installation and maintenance
    5. Continuous boot for 7 * 24 hours, deserve to trust.
    6. Support 365 days non-stop boot, the backlight life is up to 60,000 hours
    7. Splicing mode is optional.
    8. Support error and compensation function of video wall pictures
    9. Modular design according to customer demand (M * N)
    10. Diversification of the display mode

    11. Excellent display



    Commercial Video Wall​ Key features:



    1. Support a variety of signal ports.

    2. Built-in splicing module, Support splice function

    3. Support creating one window PIP across the screen, roaming service, scaling,PIP

    4. Support matrix joint control.

    5. Unique DNX motion supplement image processing technology,

    6. Dynamic image without motion trail

    7. Splicing image processing RS-232 RJ45 loop-circuit input/output.

    8. Input by remote control with wire, mobile receiver head.



    Commercial Video Wall Specifications



    Model No:

    DDW-LW460HN12

    LCD Technology Samsung a-Si TFT-LCD
    Active Screen Diagonal 46"
    Pixel Pitch(WxH)

    0.5302x0.5302mm

    Active Display Area(WxH)

    1018.08×572.67mm

    Panel Dimension(WxHxD)

    1021.98x576.57x66.9mm

    Total Bezel Width 3.5 mm
    Aspect Ratio 16:9
    Physical Resolution 1920x1080
    Backlight System LED
    Luminance(nits) 700 cd/sqm
    Contrast 5000:1 (typ.)
    Viewing Angle H 178°|V 178°
    Display Colors 8Bit,16.7M
    Refresh Rate 60Hz
    Response Time <=6ms
    Life(hrs) >60,000(hrs)
    MTBF > 100,000h
    Surface Anti-glare
    Standby Power Consumption <3W
    Maximum Power Consumption <=250W
    Power Supply AC100~240V 50/60 HZ
    Cooling Low noise fans
    Heat Dissipation 819 BTU/h (max)
    Working Time Capacity 7x24x365hours
    Application Area Indoor/Semi Outdoor/Outdoor
    Working Temperature 0°C~50°C
    Working Humidity 85% non-condensing
    Storage Temperature -20-60°C | -4-149°F
    Storage Humidity 85% non-condensing



    Commercial Video Wall Board Specification



    Support PC color 24bit
    signal   Line synchronization range 30-80KHZ
    Field synchronization range 50-75HZ
    DVI color 24bit
    HDMI Line synchronization range 30-80KHZ
    DP Field synchronization range 50-75HZ
    Interface input VGA x 1 15pin D-Sub
    DVI x 1 DVI-I
    DP x 1 Display Port
    HDMI x 2 HDMI-19 pin
    output PANEL LVDS 36Pin/2.0
    DP out DP loop out
    Power Input power DC24V/12V/5V
    Drive panel 5V/12V
    Other OSD Chinese, English and other languages (other languages can be added as required)
