Datapath 4x4 Video Wall Matrix RS232 IP Control Method Output Resolution 1920x1080

China Datapath 4x4 Video Wall Matrix RS232 IP Control Method Output Resolution 1920x1080 supplier
Datapath 4x4 Video Wall Matrix RS232 IP Control Method Output Resolution 1920x1080 supplier Datapath 4x4 Video Wall Matrix RS232 IP Control Method Output Resolution 1920x1080 supplier Datapath 4x4 Video Wall Matrix RS232 IP Control Method Output Resolution 1920x1080 supplier

Large Image :  Datapath 4x4 Video Wall Matrix RS232 IP Control Method Output Resolution 1920x1080

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: DDW
Certification: ISO9001 ,CE , RoHS , FCC , 3C
Model Number: DDW-VM0404

Payment & Shipping Terms:

Minimum Order Quantity: 1 Unit/Units
Price: Negotiable
Packaging Details: Double layer carton pack
Delivery Time: 3working days upon payment
Payment Terms: T/T,L/C,Western Union,Alibaba Trade Assurance
Supply Ability: 1000pcs/month
Contact Now
Detailed Product Description
Output Resolution: 1920x1080 Max PIP Per Screen: 1,4,16,customization
Signal Sources: HDMI,DVI,VGA,AV,YPBPR,IP Product Name: Video Wall Controller Matrix
Baud Rate: 115200 Working Time: 365x7x24hrs
AC IN: AC100-240V IR IN: 1

Datapath 4X4 Video Wall Matrix RS232 / IP Control Method





DDW Video Wall Matrix Introduction

DDW Video Wall Matrix is one of professional modularized and hardware Video wall processor which supports HDMI,DVI,VGA,AV,YPBPR, each channel support 1920 x1200 resolution signal inputs and outputs,RS232 and IP control method.Video wall processor can be widely used for:monitoring, directing, scheduling system, public security, fire, military, weather, rail, and aviation monitoring system, video conferencing, query systems.



DDW Video Wall Matrix key features:
1. Full hardware configuration without operating system
2. High-speed bus parallel processing technology, high-bandwidth uncompressed processing
3. Real time image display, no dropped frames
4. Support display at arbitrary position, at any size and any superimposed
5. Support open-window effects processing
6. Support large-screen image freeze
7. Support 7 x 24 uninterrupted and stable working
8. Flexibility to increase the input/output board
9. Support partial input and output cards with mixed interpolation
10. Input/output card supports hot-swappable, plug-and-play functionality
11. Output resolution up to 1920 x 1200



DDW Video Wall Matrix Technical Specifications

Item No. Components Descriptions QTY/signal signal type
1 Video wall Matrix SwitcherDDW-VM0404 4HDMI input ,4HDMI output , pure hardware , support multiple splicing player freely , and can show different sigal at the same time to the system,require screen built in daisy chain board 8 HDMI
2 Software Installed in PC to control,OS windows 1
3 Accessories Power plug,IR Controller,English Manual 1
input card
interface 4*HDMI type a
signal protocal HDMI 1.3, HDCP 1.3, compatible DVI1..0
EDID support
input bandwidth 165MHZ
resolution HDTV 1920*1080@60HZ, HDCP 1920*1200@60HZ
output card
interface 4*HDMI type a
signal protocal HDMI 1.3, VGA 1.0, compatible DVI1..0
output bandwidth 165MHZ
output resolution

1920x1200@60Hz,1920x1080@60Hz,1680x1050@60Hz,1600x1200@60Hz,

1600x900@60Hz,1440x900@60Hz,1400x1050@60Hz,1366x768@60Hz,

1280x1024@60Hz,1280x960@60Hz,1280x800@60Hz,1280x720@60Hz,

1024x768@60Hz,800x600@60Hz

switch effect seamless switching
System function
RS232 IN 1
IR IN 1
AC IN AC100-240V
Color System Support PAL/NTSC/SECAM
Control Type IR Remote &Software Control
Menu Language English/Chinese(Multiple Language can be customized)
Vertical/Horizontal Display Support
Combine Display Support combine any horizental &vertical numbers of screens and show display
Support combine all screens together to show one image
Solid Display Support each screen input with separate signal
PIP/Zoom/Roaming NO
Multiple Interfaces Support DVI,HDMI,VGA,AV &multiple signal inputs
Rich Resolution Support 1080P,1080I,720P,480P &multiple resolution inputs
Payment Terms &Conditions
Warranty: 3years warranty,extra fee will be charged for additional years warranty.



Technical specification of input/output connectors

VGA/RGB input Input: 15pin HD D-Sub, female
Sync mode: HV independent sync
Color Depth: 32bit/pixel
Resolution: 640*480/60HZ—1920*1200/60HZ
Input impedance :75Ω
Video input Input connector: BNC
Detecting: full-format auto detecting
Input impedance :75Ω
VGA or DVI output Resolution:1024x768/60HZ-1920x1200/60HZ
Color depth: 32bit/pixel
Output impedance:75Ω
Physical properties of input/output connectors
Signals Connectors Type
Composite VIDEO input BNC female
VGA input 15 pin HD D-Sub female
VGA output 15 pin HD D-Sub female
DVI output 24+5 or 24+1 standard female
AUX RS-232 9-pin D-Sub female
Main RS-232 9-pin D-Sub female
